BrotherHobby Avenger 0804 Motor

Purpose: Power drive for toy models, car models, airplane models, balance bikes, power tools, etc.
Specifications
KV:
10000KV/12000KV/15000KV
Base casing:
Al 7075
Stator:
8mm
Configuration:
9N12P
Prop Adapter Shaft Thread:
M1.5
Shaft:
Titanium Alloy hollow shaft
No.of Cells(Lipo):
1-2S
Bolt Pattern:
M2 (7mmX7mm)
Bearings:
Φ4*Φ1.5*2
Rotor:
N52H arc magnets
Weight:
3.4g
Wire AWG:
20AWG 16cm length
Bell cap:
Al 7075
Attributes
KV:
10000
