BrotherHobby Avenger 2816 Motor(CW)

Purpose: Power drive for toy models, car models, airplane models, balance bikes, power tools, etc.
Specifications
KV:
620KV/750KV/720KV/810KV/1050KV
Base casing:
Al 7075
Stator:
16mm
Configuration:
12N14P
Prop Adapter Shaft Thread:
M5
Shaft:
Titanium Alloy hollow shaft
No.of Cells(Lipo):
4-6S
Bolt Pattern:
M3 (19X19mm)
Bearings:
Φ12*Φ6*4
Rotor:
N52H arc magnets
Weight:
87g
Wire AWG:
18AWG 25cm length
Bell cap:
Al 7075
Variations
Edit selections
KV: 620
620
720
750
810
1050
Select variations and quantity
KV: 620
The min. inquiry quantity is 0. Add 0 more to continue.
620
-
720
-
750
-
810
-
1050
-
Subtotal
-
