BrotherHobby Tornado T10 5215 Pro Motor X Class

Purpose: Power drive for toy models, car models, airplane models, balance bikes, power tools, etc.
Specifications
KV:
170KV/330KV/380KV/500KV
Base casing:
Al 7075
Stator:
15mm
Configuration:
12N14P
Prop Adapter Shaft Thread:
M6
No.of Cells(Lipo):
6-12S
Bolt Pattern:
M4 (25X25mm);M4(30X30mm)
Bearings:
Φ15*Φ6*5
Rotor:
N52H arc magnets
Weight:
352g with 90cm SR wires
Wire AWG:
16AWG 90cm length
Bell cap:
Al 7075
Attributes
KV:
170
330
380
500
